Fockety 3 Phase 4 Wire Over Under Voltage Protector, | Ubuy

Value Adjustable: With the ability to adjust overvoltage, undervoltage, and unbalance values, as well as action times, this protector allows for customized tailored to individual needs. Multi : Offering real-time monitoring, the Protector provides comprehensive against overvoltage, undervoltage, voltage unbalance, phase error, phase loss, and zero line disconnection. 3-phase Sequence Protection Relay, 208-480VAC Three-phase Voltage Monitoring Relay, IP20, For Phase Sequence Spec: Item Type: Voltage Phase Sequence Protector Material: ABS Input Circuit: L1, L2, L3 Rated Supply Voltage: 208-480VAC 50/60Hz Working Frequency: 45-65Hz Output Type: 1CO and 1NC Overvoltage and Undervoltage Action Time: 0., 1-999s Unbalance Rate: 1-50% Unbalanced Hysteresis: 1-10% Unbalanced Delay: 0., 1-999s Phase Loss Action Time: 0., 1-30s Phase Error Action Time: 0., 1-30s Power On Delay: 0-999s Reset Mode: Auto Manual Reset Delay: 0., 1-999s Display Mode: Chinese LCD display each action status Form: 1 group of normally open and normally closed , 1 group of normally closed Capacity: 6A 250VAC 30VDC (resistive) Dimension(LxWxH): Approx., 80x43x54mm/3., 1x1., 7x2., 1in Installation Method: 35mm rail Class: IP20 Working Environment: -25? to 65?, ?85%RH Mechanical Durability: 1,000,000 times Dielectric Strength: 2kVAC 1min packing list: 1 xVoltage Phase Sequence Protector 1 x Manual Its versatility makes it a valuable asset for a variety of industries. Industrial Motor Protection Device Fockety 3 Phase 4 Wire Over Under Voltage Protector, | Ubuy 3 Phase Voltage Protector Its ultra wide voltage design makes it universal and suitable for worldwide use. COMBINED OVER/UNDER VOLTAGE MONITOR - THREE PHASE - Dorite Solar Users can have peace of mind knowing their equipment is safeguarded. Standard and Universal: The Voltage Phase Sequence Protector 3 Phase 3 Wire is designed with a standard modular structure and can be easily installed on a 35mm rail. Users can fine-tune settings for optimal performance.
